Function features Technical parameters Application scenarios

Function features

: All - weather positioning navigation and two-way message communication function

: Beidou / GPS dual-mode positioning and navigation, high positioning accuracy

: Support two Beidou user cards

: Supports a single (1 minute) 160 bytes

: Support virtual broadcast receiving function

: The terminal protection level is IP67, and the environment adaptability is strong

: Integrated design, high integration

: Compact size, simple connection, convenient installation

: Overall dimensions

Technical parameters

Items

Parameter

Overall dimensions

Φ128mm * 71mm (without support rod)

Working voltage

12V ~ 32V

Environmental indicators

Working temperature: -40℃~ +70℃, storage temperature: - 40℃~ +85℃; It can work normally at +45℃ and 95% relative humidity.

Short message length

Beidou card level 1: 110 bit = 13.75 Bytes, Beidou card level 2: 408 bit = 51 Bytes, Beidou card level 3: 628 bit = 78.5 Bytes, Beidou card level 4: 848 bit = 106 Bytes

Number of receiving channels

Application scenarios

Communication problems in remote areas without public network signals such as ocean navigation and remote mountainous areas.

Function features

All - weather positioning navigation and two-way message communication function

Beidou / GPS dual-mode positioning and navigation, high positioning accuracy

Support two Beidou user cards

Supports a single (1 minute) 160 bytes

Support virtual broadcast receiving function

The terminal protection level is IP67, and the environment adaptability is strong

Integrated design, high integration

Compact size, simple connection, convenient installation

Overall dimensions

Technical parameters

System value

Application scenarios
